Electro Magnetic Drum Separator

Continuous ferrous removal from high-tonnage bulk material flows

The Electro Magnetic Drum Separator is built for plants that need dependable, continuous removal of iron contamination from bulk materials such as sugar cane bagasse, cement raw mix, coal, and recycled aggregates. An energised electromagnetic coil inside a rotating steel drum generates a strong, deep-reaching magnetic field that captures ferrous tramp metal as material passes over the drum face. Unlike permanent designs, the field strength can be tuned to the application, making it effective on heavier burdens and larger tramp pieces. The drum is typically installed at the head pulley of a conveyor, so captured metal is automatically discharged clear of the clean product stream without stopping the line. Latif Engineering manufactures each drum separator to the belt width and throughput of the customer's line, with reinforced shells for abrasive and high-temperature material.

Adjustable magnetic field strength via DC power supply
Continuous 360° field for uninterrupted separation
Heavy-duty shell for abrasive, high-temperature material
Custom-built to belt width and throughput
Low maintenance, sealed bearing design
Automatic tramp metal discharge, no line stoppage
Suitable for retrofitting onto existing conveyor head pulleys
Protects crushers, hammer mills, and shredders from damage

Request a Quote WhatsApp Call

How it works

The unit replaces or sits beneath a conveyor's head pulley. A stationary electromagnetic coil assembly is housed inside a rotating outer drum shell. As DC current energises the coil, a continuous magnetic field is projected radially through the shell. Material discharging off the belt falls past the drum; non-magnetic product follows a normal trajectory and drops away, while ferrous tramp metal and fines are held against the rotating shell. Because the coil is fixed and only the shell rotates, the magnetic field stays active through a full 360-degree cycle rather than only part of it, which is what allows continuous, uninterrupted separation at production speed. As the shell rotates past the field's edge, captured metal releases into a separate collection chute. Field strength is adjustable through the DC power supply, so the same unit can be tuned for fine iron fines or larger tramp pieces without changing mechanical parts.

Specifications

Drum Diameter	400–1200 mm(Sized to belt width)
Drum Face Width	650–2000 mm(Matches conveyor belt width)
Magnetic Field Intensity	Up to 8000 Gauss(Adjustable via DC supply)
Power Supply	3-phase, custom DC coil(Site voltage confirmed at order)
Belt Speed Compatibility	Up to 2 m/s(Application dependent)

Final datasheet issued per confirmed application.

Applications

Sugar mill cane preparation lines, cement raw material handling, coal and biomass handling, recycling and scrap pre-sorting, and any conveyed bulk material stream that must be protected from tramp iron before crushing or grinding equipment.

Frequently asked questions

What is the difference between an electro and a permanent magnetic drum separator?

An electro drum uses a powered coil, so field strength is adjustable and generally stronger for heavier tramp iron; a permanent drum uses fixed magnets and needs no electricity but has a constant, lower field.

Can this be retrofitted onto an existing conveyor?

Yes, drums are manufactured to match your existing belt width and head pulley arrangement.

How much maintenance does it need?

Routine bearing lubrication and periodic coil insulation checks; the sealed design minimises dust ingress.

Does the field strength stay constant if the power fluctuates?

Field strength follows the DC supply, so a stabilised power source is recommended for consistent separation.
